Hot Melt Adhesive Web/Glue Material as Interlining
Description for Hot Melt Adhesive Web/Glue Material as Interlining
We supply hot melt adhesives web including Co-PA, PES, TPU and EVA.
The fusible bonding web is environment friendly and widely used in
Fabric Lamination, Apparel/Underwear, Shoes/Luggage Bags,
Acoustics, Automotive, Aerospace, Filtration, Hygiene, Healthcare
and Sporting Goods.
Specifications of Hot Melt Adhesive Web/Glue Material as Interlining
| Item Name | Hot Melt Adhesive Web/Glue Material as Interlining |
| Material | 100% Polyamide (PA) |
| Width | 0.6cm - 165cm |
| Weight | 10gsm - 80gsm |
| Color | White / Black |
| Packaging | 50m/roll, 100m/roll or as per your requirement |
| Port | Shanghai |
| Product Features | 1) Very good bondstrength, soft handfeeling |
| 2) Eco-friendly, double sided adhesive |
| 3) Soft, flat, light |
| Application | Bonding for leather, super soft materials, lamination in various
industries |
How to use
Hot melt adhesives, also called thermoplastic adhesives, are
basically blocks of thermoplastic adhesive material that can be
melted at very high temperatures and applied to a component. When a
hot melt dries, it has adhered to the component in much the same
way as glue. In fact, hot glue guns use a type of hot melt
adhesive.
Note
Above heat pressing conditions are just for reference, which are
also connected with heat pressing machine, the thickness of
material needing to be bonded and pressure. Consumers need to test
for confirmation according to concrete conditions.
Application area
1.Automotive Interior(roof, heat insulation pad, carpet, air
filter, sound-proof material, seat cover, etc)
2.Garment accessories: cuff, collar, the lower hem of clothes,
shoe, cap, bags, leather
3.home textile: curtain, bed sheet, table cloth, sofa cover,
bedding and home furnishing fabrics
4.underwear: no cracks bonding for pants, underwear, swimsuit, bra
5.computer embroidery: embroidery badge, woven label
6.conductive cloth: conductive aluminum foil and conductive foam
7.cloth bonding(sponge, nonwoven….)
Technical Data of different Hot Melt Adhesive Web
| Series | PA | EVA | PES | TPU |
| FW | FW-M | FW-L | FW-H | FWP | FWE | FWS | FWU |
| Form | web | web | web | web | web/paper | web | web | web |
| Weight(gsm) | 10~120 | 10~120 | 10~120 | 10~120 | 10~120 | 10~120 | 10~120 | 10 ~120 |
| Width(mm) | 5~1650 | 5~1650 | 5~1650 | 5~1650 | 5~1200 | 5~1650 | 5~1650 | 5~1650 |
| Melting point(℃) | 115~125 | 115~125 | 105~110 | 125~135 | 115~125 | 85~86 | 115~125 | 105~110 |
| Heating press Tem.(℃) | 130~150 | 130~150 | 110~115 | 135~160 | 130~150 | 100~115 | 130~150 | 110~130 |
| Pressing time(s) | 15~20 | 15~20 | 15~20 | 15~20 | 18~23 | 10~15 | 15~20 | 15~20 |
| Pressure(kgf/cm2) | 0.3~0.5 | 0.3~0.5 | 0.3~0.5 | 0.3~0.5 | 0.4~0.6 | 0.3~0.5 | 0.3~0.5 | 0.3~0.5 |
| Water resistant(℃) | 40 | 40 | 40 | excellent | 40 | 30 | excellent | excellent |
| Dry clean resistant(℃) | Good | Good | Good | Good | Good | X | X | excellent |
| Bond strength(N/2.5CM) | >10 | >20 | >15 | >20 | >10 | >5 | >10 | >10 |
| Characters |
| PA | FW | High bond strength, intensity, Soft, low cost, widely used |
| FW-M | Softer, middle cost |
| FW-L | Softest handfeeling, higher cost, used for high soft material |
| FW-H | High bond, intensity, suitable for washing resistence at 90℃ and
dry cleaning |
| FWP | Hotmelt adhensive with release paper for adhere the cartoons and
brands |
| EVA | FWE | Lowest cost, sutable for adhere at low temperature |
| PES | FWS | Soft, High bond, widely used |
| TPU | FWU | Soft and the resilience is very high, suitable for lycra elastic
fabric material |
Transportation & Loading port
- By sea/air/express
- Shanghai/Ningbo/Tianjin
FAQ
1. Free Samples
We provide free samples, and Receiver pay the courier charge.
Samples would be ready within 2 working days.
2. MOQ
3000 meters for general specification.
3. Delivery Time
About 7-10 days for 20'GP Container Qty.
